Honeywell Millivoltage Combination Gas Control, NG or LP, Standard Opening - 3/4" In x 3/4" Out

Honeywell Millivoltage Combination Gas Control, NG or LP, Standard Opening - 3/4" In x 3/4" Out
Our Price
Compare Prices
Shipping Info
Model: VS820A1088
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Discontinued
Sorry, this product is no longer available
Shipping Info
Shipping Info
*We currently CANNOT ship this product to California or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • How-To Articles
  • Manuals
Product Description
+
Features
Features

    Honeywell Millivoltage Combination Gas Control, NG or LP, Standard Opening - 3/4" In x 3/4" Out

    The Honeywell VS820A1088 Millivoltage Combination Gas Control combines a Lite-Rite manual gas cock, safety shutoff Pilotstat assembly, millivoltage automatic valve operator and option gas pressure regulator. It requires the use of a 750 mv Powerpile generator (thermopile). The generator, heated by the pilot burner flame, provides the electrical energy to operate the combination gas control. A millivoltage thermostat with suitable accessory controls completes the automatic control system for the heating appliance.

    Honeywell VS820A1088 Millivoltage Combination Gas Control Features:
    • Easy to install, adjust and service due to top access
    • Add separate energy cutoff where codes call for dual safety shutoff
    • Complete safety shutoff on pilot flame failure
    • LITE-RITE (OFF-PILOT-ON) lighting sequence
    Honeywell VS820A1088 Millivoltage Combination Gas Control Includes:
    • Pilot Flow Adjustment Screw
    Honeywell VS820A1088 Millivoltage Combination Gas Control Warranty:
    • Parts: 1 Year
Specifications
General Information
Product Line
VS820
Gas Type
Natural Gas
Opening Characteristic
Standard
Gas Conversion Kit
Not Convertible
UPC
085267797283
Dimensions
Supply Connection
1/2 Inch
Return Connection
3/4 Inch
Product Height
4 3/4 Inches
Product Width
4 1/16 Inches
Product Length
3 3/16 Inches
Product Weight
3.05 Pounds
Certifications
UL Listed
Yes
American Gas Association Certification
Yes
Canadian Gas Association Certification
Yes
Warranty Information
Parts Warranty Learn More A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Features
Features

    Honeywell Millivoltage Combination Gas Control, NG or LP, Standard Opening - 3/4" In x 3/4" Out

    The Honeywell VS820A1088 Millivoltage Combination Gas Control combines a Lite-Rite manual gas cock, safety shutoff Pilotstat assembly, millivoltage automatic valve operator and option gas pressure regulator. It requires the use of a 750 mv Powerpile generator (thermopile). The generator, heated by the pilot burner flame, provides the electrical energy to operate the combination gas control. A millivoltage thermostat with suitable accessory controls completes the automatic control system for the heating appliance.

    Honeywell VS820A1088 Millivoltage Combination Gas Control Features:
    • Easy to install, adjust and service due to top access
    • Add separate energy cutoff where codes call for dual safety shutoff
    • Complete safety shutoff on pilot flame failure
    • LITE-RITE (OFF-PILOT-ON) lighting sequence
    Honeywell VS820A1088 Millivoltage Combination Gas Control Includes:
    • Pilot Flow Adjustment Screw
    Honeywell VS820A1088 Millivoltage Combination Gas Control Warranty:
    • Parts: 1 Year
Specifications
General Information
Product Line
VS820
Gas Type
Natural Gas
Opening Characteristic
Standard
Gas Conversion Kit
Not Convertible
UPC
085267797283
Dimensions
Supply Connection
1/2 Inch
Return Connection
3/4 Inch
Product Height
4 3/4 Inches
Product Width
4 1/16 Inches
Product Length
3 3/16 Inches
Product Weight
3.05 Pounds
Certifications
UL Listed
Yes
American Gas Association Certification
Yes
Canadian Gas Association Certification
Yes
Warranty Information
Parts Warranty Learn More A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Product Specs
+
Specifications
General Information
Product Line
VS820
Gas Type
Natural Gas
Opening Characteristic
Standard
Gas Conversion Kit
Not Convertible
UPC
085267797283
Dimensions
Supply Connection
1/2 Inch
Return Connection
3/4 Inch
Product Height
4 3/4 Inches
Product Width
4 1/16 Inches
Product Length
3 3/16 Inches
Product Weight
3.05 Pounds
Certifications
UL Listed
Yes
American Gas Association Certification
Yes
Canadian Gas Association Certification
Yes
Warranty Information
Parts Warranty Learn More A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
