Generac 100-Amp Automatic Transfer Switch (120/208V)

Generac 100-Amp Automatic Transfer Switch (120/208V)
Our Price
Compare Prices
Shipping Info
Model: RTSN100G3
$734.00
$123 / Month
Suggested monthly payments with 6 month financing.
Factory-Direct
Ships in 4-6 Weeks
Factory items ship direct from the manufacturer.
Shipping times vary.
Shipping Crate Icon
Free Shipping
Factory-Direct
Ships in 4-6 Weeks
Free Shipping
Free Shipping
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
  • 3-Phase Automatic Transfer switch
  • Only works with 120/208 3 Phase generators
  • Fully Automatic Operation
  • Standard Installation
  • May require a sub-panel or disconnect for serviceability
  • Nema 3R Aluminum Enclosure
  • For Use With Generac Generators Only
  • UL Listed 2200
Specifications
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Rated Amps
100 Amps
Enclosure
NEMA 3R
Transfer Switch Style
Standard Installation
ATS Load Prioritizing
Not Compatible
ATS Load Shedding
Not Compatible
ATS Poles
3 Poles
Max Utility Input
100 Amps
Max Generator Input
100 Amps
UL Listed
Yes
Overview
Weight
49 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Product Length
24 Inches
Product Width
20 Inches
Product Height
7.25 Inches
UPC
696471110234
