Fantech VHR200R
Fantech VHR200R
Hover to zoom
1 Of 5

Fantech VHR - 173 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 6" Duct - Recirculation Defrost

Model:

VHR200R

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Fantech VHR - 173 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 6
Fantech VHR - 173 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 6" Duct - Recirculation Defrost
Model: VHR200R
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Fantech VHR200R Heat Recovery Ventilator (HRV) is a 200 CFM heat recovery ventilator with top ports and recirculation defrost capabilities. The VHR200R is a 120 volt unit designed with 4 ports with 6" ducts. HRVs make your heating and cooling systems more efficient by transferring heat between fresh and stale air during ventilation. Its compact size and wall bracket make this HRV easy to mount. The VHR200R Heat Recovery Ventilator (HRV) features an aluminum core, washable electrostatic filters and internal recirculation defrost.
  • Heat Recovery Core
  • An aluminum heat recovery core provides improved heat transfer capacity while taking up less space than traditional cores.
  • Winter Guard
  • A built-in recirculating defrost system allows for consistent, reliable operation during the winter months.
  • Controls
  • An External rocker switch featuring three positions (Low/Stand By/Medium) that allows for simple control of air flow.
  • Washable Electrostatic Filters
  • Electrostatic filters capture airborne particles traveling through the ventilator. Easily washable, these filters can be repeatedly reused before replacement.
  • Product Includes
  • VHR200R Heat Recovery Ventilator (HRV)
  • Mounting Bolts

Specifications

VHR200R
specs product image PID-80568
General Information
Type
HRV
Product Line
VHR
Defrost Type Learn More
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Recirculation
Ports Quantity
4
Port Location
Top
UPC
65073745617
Performance
Maximum Air Flow
202 CFM
Apparent Sensible Effectiveness
73 %
Minimum Air Flow
54 CFM
Sensible Recovery Efficiency
66 %
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Duct Connection
6 Inches
Product Height
20 1/2 Inches
Product Width
28 Inches
Product Depth
17 1/4 Inches
Product Weight
66 Pounds
Shipping Width
26 Inches
Shipping Height
19 Inches
Shipping Length
33 Inches
Shipping Weight
76 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
