Fantech VHR - 104 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 5" Duct - Recirculation Defrost

Model:

VHR 100R ES

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Fantech VHR - 104 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 5
Fantech VHR - 104 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 5" Duct - Recirculation Defrost
Model: VHR 100R ES
Was $649.00
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Fantech VHR100R ES is a 104 CFM heat recovery ventilator (HRV) with top ports defrost capabilities. The VHR100R ES is a 120-volt unit designed with 4 ports with 5" ducts. HRVs make your heating and cooling systems more efficient by transferring heat between fresh and stale air during ventilation. Its compact size makes this HRV easy to mount. The VHR100R ES Heat Recovery Ventilator (HRV) features an aluminum core, washable electrostatic filters and internal recirculation defrost.
  • Heat Recovery Core
  • An aluminum heat recovery core provides improved heat transfer capacity while taking up less space than traditional cores. Fantech designs their heat recovery cores to withstand drastic temperature variations.
  • Winter Guard™ Defrost
  • The recirculation defrost sequence automatically adjusts based on operating conditions without depressurizing your home, allowing for a smooth transition between Ventilation and Defrost mode.
  • Controls
  • An External rocker switch featuring three positions (Low/Stand By/Medium) that allows for simple control of air flow.
  • Washable Electrostatic Filters
  • Easily washable, these filters can be used throughout the life of the VHR 100R ES.
  • Easy Maintenance and Service
  • Access to all serviceable components are easily gained from the access panel.
  • Product Includes
  • (1) EZ-Mount™ Wall bracket
  • Insulated Cabinet
  • The 24 gauge galvanized steel cabinet is insulated with 1" high density expanded polystyrene. It also has a baked power coated paint for exceptional adhesion and resistance.

Specifications

VHR 100R ES
specs product image PID-83352
General Information
Type
HRV
Product Line
VHR
Defrost Type Learn More
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Recirculation
Port Location
Top
UPC
650737632342
Performance
Maximum Air Flow
131 CFM
Apparent Sensible Effectiveness
68 %
Minimum Air Flow
70 CFM
Sensible Recovery Efficiency
63 %
Electrical Data
Voltage
120 Volts
Power Consumption
168 Watts
Phase
1
Frequency
60 Hz
Current Draw
1.4 Amps
Dimensions
Duct Connection
5 Inches
Product Height
17 7/8 Inches
Product Width
22 1/2 Inches
Product Depth
14 1/2 Inches
Product Weight
39.2 Pounds
Shipping Height
17 Inches
Shipping Width
19 Inches
Shipping Length
24 Inches
Shipping Weight
50 Pounds
Certifications
Energy Star Listed
Yes
CSA Listed
Yes
HVI Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
