Buderus GB162-80LB - 260K BTU - 93.8% AFUE - Hot Water Gas Boiler - Direct Vent

Buderus GB162-80LB - 260K BTU - 93.8% AFUE - Hot Water Gas Boiler - Direct Vent
Our Price
Compare Prices
Shipping Info
Model: GB162-80LB
$5,558.00
Factory-Direct
Ships in 4-7 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping
Free Lift Gate Service -
Add-Ons

Factory-Direct
Ships in 4-7 Business Days
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    The GB162 is Buderus's pinnacle offering of high efficiency condensing technology. Advanced modulation algorithims work together with modern condensing technology to produce astoundingly high efficiency levels. The small size of the GB162 combined with its minimal installation clearances give you a notable amount of installation flexibility. Also included with the boiler is a low-loss header, an internal manifold that guarantees proper fluid flow through the inside of the boiler at all times.
  • Ultra-High Efficiency
  • The GB162's state of the art condensing technology allows the boiler to achieve an AFUE of 96%. This incredible efficiency level brings your heating bills as low as possible.
  • Included AM10 Outdoor Reset
  • The GB162 line of boilers includes an AM10 outdoor reset control for optimal efficiency during temperate months.
  • Prefabricated Low-Loss Header
  • The GB162 comes with an internal low-loss header pre-installed. It ensures proper fluid flow rate throughout the unit, extending operation lifetime and bringing installation time down to an absolute minimum.
  • Small Size and Low Installation Clearances
  • Low installation clearances on all sides, wall mounting configuration, and small footprint translate into a boiler that can be installed almost anywhere.
  • Product Note
    This boiler is a lower BTU output variation of the standard GB162-80 boiler, designed for high-altitude applications.
Specifications
General Information
Product Line
GB162
Medium Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Combustion Type
Condensing
Vent Type Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
DHW Production DHW (Domestic Hot Water) is potable water for uses other than space heat. Some boilers are able to provide DHW "out of the box", while others can do so with the purchase of optional accessories.
No
Modulating/Staging Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Modulating
Mount Type
Floor
Maximum Altitude
4000 Feet
Assembly Type
Packaged
Performance
Maximum Input Capacity The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
290000 BTU
Minimum Input Capacity
69000 BTU
DOE Heating Capacity Also referred to as Gross Output, this is the output of a boiler after accounting for combustion efficiency. We recommend sizing hot water boilers based on the DOE Heating Capacity.
260000 BTU
Net I=B=R Capacity I=B=R, also referred to as Net Output or AHRI Capacity, is the rated heat output of a boiler after accounting for combustion efficiency, piping loss, and an extra pickup factor. We recommend sizing steam boilers based on the I=B=R rating.
226000 BTU
AFUE AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
93.8 %
Ultra Low NOx Emissions NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
Yes
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Flue Connection Size
4 Inches
Gas Connection Size
1 Inch
Supply Connection
2 Inches
Return Connection
2 Inches
Product Height
51.6 Inches
Product Width
20.5 Inches
Product Depth
18.3 Inches
Product Weight
189 Pounds
Certifications
Country of Origin
Germany
CSA Listed
Yes
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Heat Exchanger Warranty
Lifetime Years
Features
Features
    The GB162 is Buderus's pinnacle offering of high efficiency condensing technology. Advanced modulation algorithims work together with modern condensing technology to produce astoundingly high efficiency levels. The small size of the GB162 combined with its minimal installation clearances give you a notable amount of installation flexibility. Also included with the boiler is a low-loss header, an internal manifold that guarantees proper fluid flow through the inside of the boiler at all times.
  • Ultra-High Efficiency
  • The GB162's state of the art condensing technology allows the boiler to achieve an AFUE of 96%. This incredible efficiency level brings your heating bills as low as possible.
  • Included AM10 Outdoor Reset
  • The GB162 line of boilers includes an AM10 outdoor reset control for optimal efficiency during temperate months.
  • Prefabricated Low-Loss Header
  • The GB162 comes with an internal low-loss header pre-installed. It ensures proper fluid flow rate throughout the unit, extending operation lifetime and bringing installation time down to an absolute minimum.
  • Small Size and Low Installation Clearances
  • Low installation clearances on all sides, wall mounting configuration, and small footprint translate into a boiler that can be installed almost anywhere.
  • Product Note
    This boiler is a lower BTU output variation of the standard GB162-80 boiler, designed for high-altitude applications.
