Triangle Tube PT60
Triangle Tube PT60
Hover to zoom
1 Of 5

Triangle Tube PT60 - 54K BTU - 95.0% AFUE - Hot Water Gas Boiler - Direct Vent

Model:

PT60

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Triangle Tube PT60 - 54K BTU - 95.0% AFUE - Hot Water Gas Boiler - Direct Vent
Triangle Tube PT60 - 54K BTU - 95.0% AFUE - Hot Water Gas Boiler - Direct Vent
Model: PT60
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Triangle Tube is best known for two things: feats of hydronic innovation and incredibly efficient products. The Prestige Solo line of hot water boilers marries high efficiency condensing technology with Triangle Tube's cutting edge TriMax controls to bring you a boiler that is 95% efficient and simple to operate. The condensing technology behind Prestige Solo boilers will capture and reuse gaseous heat that escapes traditional boilers. Stainless steel construction and an internal condensate trap will protect the PT60 from corrosion. Prestige Solos also include a modulating burner that scales heat production based on your needs and reduces unnecessary energy consumption. The TriMax control allows you to have two different temperature zones and six Prestige boilers in your system. It also displays all problems in clear English and suggests common solutions. With the TriMax, controlling and maintaining your boiler is easier than ever. The Prestige Solo is an overachiever in every regard, and it makes an excellent addition to any system.

    Product Features

    60 Second Setup
    TriMax controls feature six preprogrammed applications that allow you to set the PT60 up in just one minute. These applications are: finned tube baseboard, cast-iron baseboard, radiators, high mass radiant, and low mass radiant. Even if your application is not listed, the TriMax will save time with its easy-to-read display and clear commands.

    Fire Tube Heat Exchanger
    The Prestige Solo line of hot water boilers includes a fire tube heat exchanger. By allowing for high water content, fire tube heat exchangers reduce short cycling and provide incredibly steady temperatures. Contours in the design prevent any detritus from accumulating, which keeps your PT60 running efficiently.

    Outdoor Reset Control
    All Prestige Solo boilers include an outdoor temperature sensor. When connected to the TriMax control, this sensor allows you to use outdoor reset control to provide the ideal indoor temperature. Outdoor reset control saves energy and keeps you comfortable, even in changing weather conditions.

    TriMax Control
    The TriMax control is one of the most versatile proprietary controls in the business. It includes warm weather shutdown, low water cut off, and allows your system to interface with Modbus communications protocols. It is easier than ever to stay safe and efficient with a Prestige Solo and TriMax controls.

    Product Includes
    • (1) Triangle Tube PT60 Hot Water Boiler
    • (1) Outdoor Reset Sensor
    • (1) TriMax Control Module
    • (1) Wall Mounting Bracket
    • (1) Natural Gas to Liquid Propane Conversion Kit

Specifications

PT60
specs product image PID-23140
General Information
Product Line
Prestige TriMax Solo
Medium Learn More
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Combustion Type Learn More
Combustion Type
Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
Condensing
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
DHW Production Learn More
DHW Production
DHW (Domestic Hot Water) is potable water for uses other than space heat. Some boilers are able to provide DHW "out of the box", while others can do so with the purchase of optional accessories.
No
Modulating/Staging Learn More
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Modulating
Connection Type
NPT
Mount Type
Wall
Minimum Altitude
0 Feet
Maximum Altitude
2000 Feet
Assembly Type
Packaged
Gas Conversion Kit
Not Convertible
Performance
AFUE Learn More
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
95 %
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
60000 BTU
Minimum Input Capacity
16000 BTU
DOE Heating Capacity Learn More
DOE Heating Capacity
Also referred to as Gross Output, this is the output of a boiler after accounting for combustion efficiency. We recommend sizing hot water boilers based on the DOE Heating Capacity.
54000 BTU
Net I=B=R Capacity Learn More
Net I=B=R Capacity
I=B=R, also referred to as Net Output or AHRI Capacity, is the rated heat output of a boiler after accounting for combustion efficiency, piping loss, and an extra pickup factor. We recommend sizing steam boilers based on the I=B=R rating.
47000 BTU
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Flue Connection Size
3 Inches
Supply Connection
1 Inch
Return Connection
1 Inch
Product Height
35 1/2 Inches
Product Width
20 Inches
Product Depth
16 Inches
Shipping Weight
95 Pounds
Certifications
ETL Listed
Yes
Energy Star Listed
Yes
ASME Certified
Yes
AHRI Certified
Yes
ISO Certified
Yes
AHRI Reference Number
2101293
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Heat Exchanger Warranty
10 Years
