Taco VRTX100-3
Taco VRTX100-3
Hover to zoom
1 Of 5

Taco VorTech - Air Separator - 1" NPT

Model:

VRTX100-3

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
View Taco 4900 Series - Air Separator - 1
Model:
49-100T-2
$113.03
Factory-Direct
Taco VorTech - Air Separator - 1
Taco VorTech - Air Separator - 1" NPT
Model: VRTX100-3
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

    The VRTX100-3 is a Taco VorTech air separator. It combines unique design elements with a reliable Taco high capacity Hy-Vent automatic air vent. The VorTech series has two stages of air separation. In the first stage, the Hy-Vent automatically pulls the largest air bubbles out. The smaller bubbles are then handled by a vortex created at the center of the VRTX100-3 by its distinct dual chamber design. The vortex drags water across a bubble breaking screen, which removes air bubbles from the flow and pushes them towards the vent. The vortex also creates a pressure differential that drags any bubbles missed by the screen to the center of the separator, where the Hy-Vent can easily expel them.
  • Easy Installation
  • It's easy to find a spot to install the VRTX100-3, VorTech air separators have no required minimum piping run.
  • Straightforward Servicing
  • A clogged or leaky vent is easy to address in a VorTech air separator. The included 419-1 Hy-Vent is removable, for quick cleaning and simple replacement.
  • Expansion Tank Support
  • Adding an expansion tank to the VRTX100-3 is a breeze. VorTech air separators feature a convenient 1/2" NPT connection at their base.
  • Product Includes
  • (1) Taco VRTX100-3 VorTech Air Separator
  • (1) Taco 419-1 Hy-Vent Automatic Air Vent
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

VRTX100-3
specs product image PID-33735
General Information
Product Line
VorTech
Material
Cast Iron
UPC
687752202205
Performance
Maximum Fluid Temperature
240 F
Maximum Operating Pressure
150 PSI
Dimensions
End 1 Connection Type
NPT
End 1 Connection Size
1 Inch
End 2 Connection Type
NPT
End 2 Connection Size
1/2 Inch
Product Height
7 5/8 Inches
Product Width
5 3/4 Inches
Product Depth
3 Inches
Shipping Weight
7 Pounds
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
