Noritz NC380-SV-ASME-NG
Noritz NC380-SV-ASME-NG
Hover to zoom
1 Of 5

Noritz NC380-SV-ASME - 8.9 GPM at 70° F Rise - 80% TE - Gas Tankless Water Heater - Power Vent or Outdoor - ASME Certified

Model:

NC380-SV-ASME-NG

Write A Review
$4,887.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 4-7 Business Days
synchrony card logo
$62 / Month
With our 132 months 9.99% APR*
132 fixed monthly payments required.
Noritz NC380-SV-ASME - 8.9 GPM at 70° F Rise - 80% TE - Gas Tankless Water Heater - Power Vent or Outdoor - ASME Certified
Noritz NC380-SV-ASME - 8.9 GPM at 70° F Rise - 80% TE - Gas Tankless Water Heater - Power Vent or Outdoor - ASME Certified
Model: NC380-SV-ASME-NG
$4,887.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Noritz has been in the business of providing homes with hot water for over sixty years, and introduced the industries first electronically controlled water heater in 1981. The NC380-SV-ASME-NG represents the culmination of the experience gained over those sixty years. Noritz Commercial tankless water heaters are engineered to perform with efficient precision, making these units perfect for any commercial project. These fully modulating units are designed with commercial grade copper heat exchangers that allow for optimal performance and are backed by a five-year heat exchanger warranty.Product Features
  • Built for Efficiency
  • The NC380-SV-ASME-NG boasts an 80% thermal efficiency rating and a direct electronic ignition that avoids always-on pilot light installations, saving you fuel and money.
  • Made with Safety in Mind
  • Noritz tankless water heaters have built-in safety devices that protect your unit including a flame sensor, overheat prevention device, lightning protection device, and freeze protection device, all backed by a five-year parts warranty.
  • Temperature Control
  • The Noritz NC380-SV-ASME-NG includes an easy-to-use thermostat attached to the front panel, allowing for convenient temperature control for your hot water system.
  • Compact, Modern Design
  • Noritz tankless water heaters are engineered to have a compact design that easily allows for indoor or outdoor installation.
  • Multiple Unit System Compatibility
  • For extra-demanding systems, the Noritz NC380-SV-ASME-NG unit can also be linked together with up to 24 units.
  • Product Includes
  • (5) Tapping Screws
  • (1) Remote Controller
  • (10') Remote Controller Cord
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

NC380-SV-ASME-NG
specs product image PID-31838
Overview
Product Category
Water Heater - Commercial
UPC
817000010386
General Information
Type
Tankless Water Heater
Product Line
Commercial
Product Category
Water Heater - Commercial
Medium Learn More
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Combustion Type Learn More
Combustion Type
Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
Non-Condensing
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Power Vent
Venting Category Learn More
Venting Category
Venting Category describes what type of flue material can be used in water heater installations. Category III: Stainless Steel, Category IV: ABS, PVC, CPVC, PolyPro, Stainless Steel
III
Storage Type
Tankless
Mount Type
Wall
Installation Location
Indoor / Outdoor
Includes Pump
No
Gas Conversion Kit
Not Available
Performance
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
380000 BTU
Minimum Input Capacity
22500 BTU
Flow Rate at 70F Temperature Rise Learn More
Flow Rate at 70F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
8.9 GPM
Efficiency Type
Thermal
Thermal Efficiency
80 %
Ultra Low NOx Emissions Learn More
Ultra Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
No
Low NOx Emissions Learn More
Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Low NOx appliances emit less than 40 ng/J (nanogram per Joule) of NOx. Learn More
Yes
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
3/4 Inch
Flue Connection Size
5 Inches
Cold Water Inlet
1 Inch
Hot Water Outlet
1 Inch
Product Height
29 1/2 Inches
Product Width
19 5/48 Inches
Product Depth
11 19/24 Inches
Product Weight
105 Pounds
Shipping Weight
115 Pounds
Certifications
CSA Listed
Yes
ASME Certified
Yes
NSF Certified Learn More
NSF Certified
The National Sanitation Foundation has developed public health standards and certification programs to protect the world's food, water, consumer products and environment.
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
5 Years
