Fantech RVF 254 CFM Exterior Duct Fan Wall Mount 4" Duct

Model:

RVF4XLEC

Write A Review
Not For Individual Sale
Continue Shopping With These Categories
Fantech RVF 254 CFM Exterior Duct Fan Wall Mount 4
Fantech RVF 254 CFM Exterior Duct Fan Wall Mount 4" Duct
Model: RVF4XLEC
Not For Individual Sale
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Featuring a galvanized steel housing, the Fantech RVF4XLEC Centrifugal Exterior Duct Fan is the perfect solution for direct through-wall ventilation where quiet operation is required in residential or commercial applications. RVF fan motors mount to the outside wall of the building limiting noise from operation. This 120 volt model can produce a maximum airflow of up to 254 CFM. The RVF4XLEC is constructed with a 4" round duct.
  • Permanently Lubricated Sealed Ball Bearings
  • Permanently lubricated sealed ball bearings extend the service life of your fan.
  • Quiet Operation
  • By having the ability to be installed outdoors, all of the ambient noise is kept outside.
  • 100% Speed Controllable
  • On-demand ventilation and precision balancing of systems is controllable through voltage reduction. A pre-wired speed control potentiometer is included to control the EC motor for the most efficient solution for your needs.
  • Easy Inspection
  • By being located on an outside wall, you have easy access to the fan. This unit comes with a removable housing for immediate access to the motor and wiring.
  • High Efficiency Motor
  • The RVF4XLEC features a high efficiency EC motor that both reduces energy consumption and also provides 100% speed control.

Specifications

RVF4XLEC
specs product image PID-64909
Overview
Product Category
Fans
UPC
650737448608
General Information
Type
Exterior Duct Fan
Product Line
RVF
Product Category
Fans
Mount Type
Wall
Housing Material
Galvanized Steel
Performance
Maximum Air Flow
254 CFM
Electrical Data
Voltage
120 Volts
Power Consumption
85.5 Watts
Phase
1
Frequency
60 Hz
Dimensions
Duct Connection
4 Inches
Product Height
13 Inches
Product Width
10 1/4 Inches
Product Length
6 Inches
Shipping Width
11 Inches
Shipping Height
14 Inches
Shipping Depth
8 Inches
Shipping Weight
12 Pounds
Certifications
UL Listed
Yes
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
