Fantech FRD 2,074 CFM Inline Duct Fan 24 x 14" Duct 230V

Model:

FRD24-14-230

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Fantech FRD 2,074 CFM Inline Duct Fan 24 x 14
Fantech FRD 2,074 CFM Inline Duct Fan 24 x 14" Duct 230V
Model: FRD24-14-230
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

    The Fantech FRD 24-14-230 Rectangular Inline Duct Fan is a 2,074 CFM centrifugal supply and exhaust fan designed for large ventilation in areas of limited space. It is constructed for 24 x 14 inch venting. FRD Series Duct Fans can install directly within equally sized rectangular ductwork without the need for transitions. The motor is mounted on a hinged door for easy access. This unit is wired for 230 volts.
  • Duct-to-Duct Installation
  • A compact rectangular design allows for installation directly within rectangular ductwork without the need for large elbows or transitions.
  • Easy Maintenance
  • All serviceable components are easily accessible in under 5 minutes.
  • Backward Curved Impeller
  • Backward curved impeller blades allow particles to easily pass through the fan blades, preventing a build-up.
  • 100% Speed Controllable
  • On-demand ventilation and precision balancing of systems is controllable through voltage reduction.
  • Permanently Lubricated Motor
  • Permanently lubricated sealed ball bearings keep your fan working maintenance-free.

Specifications

FRD24-14-230
specs product image PID-31470
Overview
Product Category
Fans
UPC
650737440039
General Information
Type
Duct Fan
Product Line
FRD
Product Category
Fans
Mount Type
Inline
Housing Material
Galvanized Steel
Performance
Maximum Air Flow
2074 CFM
Maximum Sound Level Learn More
Maximum Sound Level
The sone is a unit of loudness, or how loud a sound is perceived. For reference, the loudness of rustiling leaves is around 0.02 sones, a quiet running refrigerator is around 2 sones, and a running car is around 4-16 sones.
20.6 Sones
Electrical Data
Phase
1
Frequency
60 Hz
Current Draw
3.6 Amps
Dimensions
Duct Connection
24 Inches
Product Height
13 3/4 Inches
Product Width
23 5/8 Inches
Product Length
28 1/2 Inches
Product Weight
86 Pounds
Shipping Width
28 Inches
Shipping Height
20 Inches
Shipping Length
32 Inches
Shipping Weight
96 Pounds
Certifications
UL Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
3 Years
