Aspen Silent+ Mini Orange - Mini Split Condensate Pump Kit - 115V - Up to 54,000 BTU/hr

Model:

ASP-MO-115-SP

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Aspen Silent+ Mini Orange - Mini Split Condensate Pump Kit - 115V - Up to 54,000 BTU/hr
Aspen Silent+ Mini Orange - Mini Split Condensate Pump Kit - 115V - Up to 54,000 BTU/hr
Model: ASP-MO-115-SP
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    A properly functioning mini split system requires an installation that allows for proper condensate drainage. Condensate removal pumps are used in situations where gravity draining is not an option. If you're using a high wall system, ducted or free-standing units, you may need an alternative way to expel water that has been removed by the cooling system. Aspen's ASP-MO-115SP Mini Orange Silent+ Condensate Pump is the quietest pump in its class, designed to enhance the World's No. 1 mini pump's performance by focusing on silent operation. This condensate pump is easy to use and install, with a simple plug-and-play operation. Aspen's ASP-MO-115SP is perfect for being installed directly in the unit and is so small and quiet, you'll never even know it's there.
  • Silent+ Technology
  • Complete with an acoustic damper and Silent+ technology, the ASP-MO-115SP is a small yet powerful solution for any situation, even in sound-sensitive applications.
  • Designed for Versatile Installation
  • Aspen Mini Split Condensate Pump Kits like the ASP-MO-115SP are not only designed to be truly silent systems, but also to focus on reliability with an anti-siphon device to keep air from seeping into your pump and causing priming issues.
  • Performance that Packs a Punch
  • The ASP-MO-115SP has a max flow rate of 3 GPM that'll keep your system running smoothly. Each unit also features an anti-siphon device that makes sure your pump is always primed, keeping air from leaking in and causing problems.
  • Plug & Play
  • The ASP-MO-115SP is a no hassle, low maintenance unit that's ready to go right out of the box. Just hook up the pump and you're set.
  • Product Includes
  • (1) 1.5m Plug & play power cable
  • (1) 300mm Discharge Tube 6mm ID
  • (1) Acoustic Damper and 1m Orange Discharge Tube
  • (1)Anti Vibration Bracket
  • (1) 220 Orange Inlet Hose 14mm ID
  • (1) Standard Reservoir
  • (1) Optional Submersible Reservoir
  • (1) 150mm Vinyl breather tube 6mm ID
  • (1) Anti siphon device
  • (1) Drain connector kit
  • (1) Fixing kit
  • (1) Install manual
  • Product Note
    The Aspen ASP-MO-115-SP is suitable for use with small commercial and domestic ducted, floor standing and high wall mounted mini split systems. The ASP-MO-115-SP is designed for above ceiling, inside conduit or inside evaporator installation and is ideal for applications where silence is key.

Specifications

ASP-MO-115-SP
specs product image PID-50135
General Information
Type
Condensate Pump
Product Line
Silent+ Mini Orange
Application
Standard
UPC
021449839112
Additional Model Numbers

ASP-MO-115SP, ASP-MO-115-SP

Performance
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
54000 BTU
Suction Lift
6.56 Feet
Maximum Head
32.81 Feet
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
19 dB
Condensate Removal Rate
3 GPH
Electrical Data
Current Draw
0.1 Amps
Dimensions
Product Height
1 1/3 Inches
Product Width
1 13/24 Inches
Product Depth
3 7/48 Inches
Product Weight
0.55 Pounds
Certifications
Country of Origin
UK
CSA Listed
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
