Aspen Maxi Orange - Mini Split Condensate Pump Kit - Universal Voltage - Up to 157,000 BTU/hr

Model:

ASP-MAXO-UNI

Write A Review
$320.37
Closeout Item Icon
Closeout Item
Product Discontinued
Ships Wednesday, Apr 17th
Shipping to60601
synchrony card logo
$54 / Month
Suggested monthly payments with 6 month financing.
Aspen Maxi Orange - Mini Split Condensate Pump Kit - Universal Voltage - Up to 157,000 BTU/hr
Aspen Maxi Orange - Mini Split Condensate Pump Kit - Universal Voltage - Up to 157,000 BTU/hr
Model: ASP-MAXO-UNI
$320.37
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    A properly functioning mini split system requires an installation that allows for proper condensate drainage. Condensate removal pumps are used in situations where gravity draining is not an option and more power is needed. If you're using a high wall system, ducted or free-standing units, you may need an alternative way to expel water that has been removed by the cooling system. Aspen's ASP-MAXO-UNI Maxi Orange Condensate Pump is a compact and discrete pump, designed for great performance with its high power motor and submersible secondary reservoir. Aspen's ASP-MAXO-UNI is perfect for large commercial applications.
  • Designed for Versatile Installation
  • Aspen Mini Split Condensate Pump Kits like the ASP-MAXO-UNI are designed to not only that extra boost of performance for your more demanding systems, but also to focus on reliability with an anti-siphon device to keep air from causing priming issues.
  • Performance that Packs a Punch
  • The ASP-MAXO-UNI has a max flow rate of 9 GPM that'll keep your system running smoothly. Each unit also features an anti-siphon device that makes sure your pump is always primed, keeping air from leaking in and causing problems.
  • Plug & Play
  • The ASP-MAXO-UNI is a no hassle, low maintenance unit that's ready to go right out of the box. Just hook up the pump and you're set.
  • Universal Voltage
  • The Aspen ASP-MAXO-UNI Maxi Orange is compatible with all voltages allowing for an easy integration into your existing components.
  • Product Includes
  • (1) 1.5m Plug & play power cable
  • (1) Standard Reservoir
  • (1) Optional Submersible Reservoir
  • (1) 150mm Vinyl breather tube 6mm ID
  • (1) Anti siphon device
  • (1) 1.5m Suction Tube 6mm ID
  • (1) 220mm Orange inlet hose 14mm ID
  • (1) Drain connector kit
  • (1) Fixing kit
  • (1) Install manual
  • Product Note
    The Aspen ASP-MAXO-UNI is suitable for use with large commercial high wall split systems, ducted units and floor mounted units. The ASP-MAXO-UNI is designed for above ceiling, inside conduit or behind evaporator installation.

Specifications

ASP-MAXO-UNI
specs product image PID-50129
General Information
Type
Condensate Pump
Product Line
Maxi Orange
Application
Standard
UPC
021449839198
Performance
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
157000 BTU
Suction Lift
6.56 Feet
Maximum Head
49.21 Feet
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
35 dB
Condensate Removal Rate
9 GPH
Electrical Data
Current Draw
0.1 Amps
Dimensions
Product Height
1 1/3 Inches
Product Width
1 13/24 Inches
Product Depth
3 7/48 Inches
Product Weight
0.99 Pounds
Certifications
Country of Origin
UK
CSA Listed
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
