Amtrol Therm-X-Span - 4.4 Gallon - In-Line Thermal Expansion Tank

Model:

T-12

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Amtrol Therm-X-Span - 4.4 Gallon - In-Line Thermal Expansion Tank
Amtrol Therm-X-Span - 4.4 Gallon - In-Line Thermal Expansion Tank
Model: T-12
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

    In 1954, Amtrol invented the first expansion tank to control pressure build-up in closed, hot water systems. Today they are continuing to roll out efficient and reliable tanks to improve your system. The T-12 in-line thermal expansion tank is a perfect example of this. By accepting expanded water caused by thermal expansion, the T-12 is able to then return the water to the system when hot water is used. It also prevents pressure relief valve discharge, dripping faucets, and intermittent toilet fill. From the strong, steel dome to the welded air charge fitting, T-12 is designed to prevent damaging pressure buildup and eliminate energy and water waste.

    Product Features

    USA Made
    All T thermal expansion tanks are made in the USA at facilities certified for maintaining high-quality standards.

    Protection for Your System
    T thermal expansion tanks are designed to protect your water heater, fixtures, and appliances by preventing dangerous pressure build up.

Specifications

T-12
specs product image PID-23185
General Information
Product Line
Therm-X-Span
Connection Type
NPT
Color
Tan
UPC
642031560889
Performance
Maximum Operating Temperature
200 F
Maximum Operating Pressure
150 PSI
Dimensions
Storage Volume
4.4 Gallons
Maximum Acceptance Volume
3.2 Gallons
Connection Size
3/4 Inch
Product Diameter
11 Inches
Product Height
15 Inches
Shipping Width
11 Inches
Shipping Height
15 Inches
Shipping Length
11 Inches
Certifications
Country of Origin
USA
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
